Most all wireless networks have tests for signal strength. Generally line of sight (LOS) is a good rule.
The direction it is pointing and the vertical angles are important. Hook up your cable from the wireless device external antenna port, point the antenna at another device and test the antenna. It should be perpendicular to the shell of the cylinder when mounted in the connector and the connector to the can. The length from the connector that worked best for me was 1.21 inches. Before actually mounting the connector, prepare the 12 gauge wire to be soldered onto the brass stub of the connector. The shell of the connector does ground to the can. The center conductor that will be soldered to the brass stub cannot ground against the can. Drill or punch holes in your can to mount the connector the length of the 1/4 wave guide from the closed end of the can. Enter the diameter of the can and click on Calculate. The calculator will provide the approximate numbers for actual installation of the connector into the side of the can cylinder. While there is no exact length of the can cylinder, the longer the can, the better the performance but the more directional it is. Some tried cans 6 to 7.5 inches in diameter. The other people trying this have used other sizes between 3 inches and 3.75 inches with success. The can that worked best for me was 3.25 inches in diameter. The other side has a small brass stub for attaching the small piece of wire with solder. One side is N-female for connecting the cable from your wireless equipment. We will mount this to the our recycled directional dish. Most came so that they mount by way of four small screw or nuts and bolts some had other mounting brackets. Hams and electronics hobbyists may have one hiding in the junk box. The N type female chassis mount connector is typically used in radio applications. Several small nuts and bolts or other mounting hardware for mounting the connector. 1 - Copper 12 gauge wire about 2 inches long.ģ. 1 - N-Type Female chassis mount connector.Ģ. Call it scavenging or preparation it should not take long.
In order to do this, you will need to gather a group of materials needed. We assume no responsibility or liability. While this has worked very well for me, there is a certain amount of risk to equipment any time you experiment. Total time should be under an hour and total cost under $10.00, even if you don't have an electronics junk box at home. Whatever you call it, it is an interesting project that takes very little time and very little money. We like to call it a recycled waveguide antenna. This idea is not new and has many names such as shell cell, cantenna, bazooka antenna, canned antenna and tin can annie. Here is a do it yourself (DIY) project that is an inexpensive way to increase the range of your wireless network or cordless phone. Wireless Networks And Other 2.4GHz Applications Low Cost Home Brew Waveguide Antenna For 802.11b Detailed experimentation guidelines are below the calculator. This calculator is designed to give experimentation data for construction and use of a wireless range extending antenna.
This calculator requires the use of Javascript enabled and capable browsers. Wireless 2.4 GHz Directional Antenna Calculator
